₹730,000.00
The new ASUS RS920-E7/RS8 server is based the latest Intel® server platform, using 4-way Xeon® Romley-EP 4S processors. Equipped with 32 DIMM slots, eight hot-swap hard drives, 6+1 expansion slots, and 1+1 redundant power supplies, it lays a great foundation for data centers, HPC, and enterprise applications that require outstanding performance, supercomputing capabilities, and high reliability.
Out of stock
The new ASUS RS920-E7/RS8 server is based the latest Intel® server platform, using 4-way Xeon® Romley-EP 4S processors. Equipped with 32 DIMM slots, eight hot-swap hard drives, 6+1 expansion slots, and 1+1 redundant power supplies, it lays a great foundation for data centers, HPC, and enterprise applications that require outstanding performance, supercomputing capabilities, and high reliability.
| Processor | Single Processor E5-4650*4 (32 Core) |
|---|---|
| RAM | 1024 GB RAM |
| HDD Bays | 8 x 3.5" HDD BAY |
| Form Factor | 2U |
| Processor / System Bus | Intel® Xeon® processor E5-4600 product family (130W) Intel® Xeon® processor E5-4600 v2 product family (130W) 4 x Socket 2011 |
| Core Logic | Intel® C602-A PCH |
| Memory | Memory Size : * Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU. *16GB, 8GB, 32GB LRDIMM 32GB, 1GB, 4GB, 8GB, 2GB, 16GB RDIMM 1GB, 4GB, 2GB, 8GB UDIMM Memory Type : LRDIMM 1333/1066 DDR3* DDR3 UDIMM 1600/1066/1333 * RDIMM 1333/800/1600/1066 DDR3* Capacity : Maximum up to 1024GB LRDIMM/Maximum up to 1024GB RDIMM/Maximum up to 256GB UDIMM Total Slots: 32 |
| Storage | SATA Controller : 2 x SATA3 6Gb/s ports Intel® C602-A Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only) (Support Software RAID 1, 10, 0, 5 ) LSI® MegaRAID (For Linux/Windows) (Support Software RAID 10, 0, 1 ) 4 x SATA2 3Gb/s ports |
| Expansion Slots | Full-length 4 * PCI-E x16 (2 * Gen3 x16 Link or 4 * Gen3 x8 Link) Half-length/Low-profile 2 * PCI-E x8 (Gen3 x8 Link) |
| Networking | 1 x Quad Port Intel Ethernet Controller i350-AM4 + 1 x Mgmt LAN |
| Graphic | Aspeed AST2300 with 16MB VRAM |
| On Board I/O | 5 x RJ-45 ports (One for ASMB6-iKVM) 2 x USB 3.0 ports 1 x Internal A Type USB Port 1 x VGA port 1 x External Serial Port 6 x USB 2.0 ports (Front x 2, Rear x 1)*4 1 x PS/2 KB/MS port |
| OS Support | Windows® Server 2008 R2RedHat® Enterprise Linux AS5.6/6.0 32/64-bit SuSE® Linux Enterprise Server 11.2 32/64-bit Windows® Server 2008 Enterprise 32/64-bit Windows® Server 2008 R2 Enterprise VMWare ESX4.1/ESXi4.1 CentOS 5.6 32/64-bit |
| Management Solution | default 1 x ASMB6-iKVM for KVM-over-IP |
| Regulatory Compliance | CE, C-Tick, FCC(Class A), BSMI |
| Dimensions | 750mm * 444mm * 88mm |
| Weight | 20Kg |
| Power Supply | 1620W (80+) (Platinum level) 1+1 Redundant Power Supply (following different configuration by region) |
| Environment | Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) |
| Accessory Box | 1 x RS920-E7 User’s Guide 1 x ASUS ASWM Enterprise User’s Guide 1 x Bag of Screws 2 x AC Power Cable 1 x ASWM ENTERPRISE DVD 1 x RS920-E7 Support DVD 1 x ASMB6 SERIES DVD 1 x ASMB6 User’s Guide |
| Optional Items | Second 1620W Redundant Power Supply Module (04G180001700) ASUS PIKE 2008 RAID card (90-S00CS0130T) ASUS PIKE 2008/IMR RAID card (90-S00CS0140T) ASUS PIKE 2108-32PD H/W RAID card (90-S00CS0150T) ASUS PIKE 2208 H/W RAID card (90SKC000-M00AN0) ASUS PIKE 2308 RAID card (90SKC000-M08AN0) |
| Chassis | ASUS R21C 2U Rackmount Chassis |
| MB | ASUS Z9PX-Q32 Server board |
| HDD Backplane | 1 x RS920-X7/RS8 SAS/SATA Backplane (BP8LX-R21B) (60SC0180-SC0A02) |
| Front Panel Board | 1 x Front I/O Board (FPB-AR14) (60SC0070-SC0C05) |
| Power Distribution Board | 1 x Power Distribution Board (60SC0200-SC0A01) 1 x Power Distribution Extension Board (60SC0210-SC0A01) |
| CPU Heatsink/ Cooler | 4 x CPU Heatsink (13071-00090600) |
| Power Supply Unit | 2 x 1620W Redundant Power Supply (04G180001700) |
| HDD Tray | 8 x Hot-swap 3.5″ HDD trays (13GS1I0AM010-1) |
| Fan | 5 x System Fans(80mm x 38mm) (13070-00230000) |
| Optical Drive | 1 x Slim DVD-RW (Optional) (17G14113400N) |
| Mounting Rails | 1 x Tool-less rail kit (13SV0006AM0801) |
