Asus Rack Server ESC 4000 G2S level3


The ASUS ESC4000-FDR G2S is the latest supercomputer based on the dual Intel® Xeon® E5-2600 v2 processor platform, featuring streamlined design for improved airflow and lower running costs, six vertically-oriented hot-swappable 2.5″ SATA HDD bays, 1+1 80 PLUS 1620W Platinum redundant power supplies and 8+1 PCI-E Gen3 x16 expansion slots. It delivers high density computing power, scalable expansion capability and an intelligent thermal solution, all in a green design, making it an ideal choice for the applications in the field of life and medical science, engineering science, financial modeling and virtualization.

Out of stock



ProcessorDual Processor E5-2680 v2
Ram128 GB
Form Factor2U
Graphics Card8 X Nvidia 1070


Processor / System Bus
Intel® Xeon® processor E5-2600 product family
Intel® Xeon® processor E5-2600 v2 product family
2 x Socket 2011
QPI 6.4 / 7.2 / 8.0 GT/s
*Refer to support page for more information
Core LogicIntel® C602-A PCH
Mellanox ConnectX-3 FDR
MemoryMemory Type :
DDR3 1066/1600/1333/1866 UDIMM*1
DDR3 RDIMM 1866/1066/1600/1333*1
1866/1600/1333/1066 LRDIMM DDR3*1
Total Slots : 16 (4-channel per CPU, 8 DIMM per CPU)
Memory Size :
1GB, 4GB, 16GB, 8GB, 2GB, 32GB RDIMM
Capacity : Maximum up to 512GB LRDIMM/Maximum up to 512GB RDIMM/Maximum up to 128GB UDIMM
StorageSATA Controller :
Intel® C602-A AHCI
2 x SATA3 6Gb/s ports
Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 1, 0, 10, 5 )
LSI® MegaRAID (For Linux/Windows)
(Support Software RAID 0, 1, 10 )
SATA Controller :
Intel® C602-A SCU
4 x SATA2 3Gb/s ports
Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 1, 5, 10, 0 )
SAS Controller :
Support with riser card
ASUS PIKE 2208 8-port SAS 6G HW RAID card (Optional)
ASUS PIKE 2008 8-port SAS2 6G RAID card (Optional)
ASUS PIKE 2308 8-port SAS 6G RAID card (Optional)
ASUS PIKE 2108 8-port SAS2 6G RAID card (Optional)
HDD Bays6 x Hot-swap 2.5″ HDD Bays
Networking2 x Intel® 82574L + 1 x Mgmt LAN
GraphicAspeed AST2300 with 16MB VRAM
On Board I/O1 x VGA port
3 x RJ-45 ports (One for ASMB6-iKVM)
1 x Internal A Type USB Port
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x External Serial Port
OS SupportCentOS 5.7/6.2 32/64-bit
SuSE® Linux Enterprise Server 11.2 32/64-bit
Windows® Server 2012
RedHat® Enterprise Linux AS5.7/6.2 32/64-bit*Subject to change without any notice
Windows® Server 2008 Enterprise R2 SP1 64-bit
Windows® Server 2012 R2
VMWare ESX4.1/ESXi4.1
Windows® Server 2008 Enterprise SP2 64-bit
Management SolutionASWM Enterprise
on board 1 x ASMB6-iKVM for KVM-over-Internet
Regulatory ComplianceBSMI, CE, FCC(Class A)
Dimensions750mm x 444mm x 87mm(2U)
Power Supply1+1 Redundant 1620W 80PLUS Platinum Power Supply;
1000W: 100-120Vac, 12-10A, 50-60Hz, Class I
1200W: 120-140Vac, 12-10A, 50-60Hz, Class I
1620W: 180-240Vac, 10.5-8A, 50-60Hz, Class I
EnvironmentOperation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
Accessory Box1 x ESC4000 G2S User’s Guide
1 x Bag of Screws
1 x AC Power Cable
1 x C60x Support DVD
1 X ASWM Enterprise DVD
1 x ASMB6 Manual
Optional ItemsSecond 16200W Redundant Power Supply Module (04G180001700)
Heatsink for CPU 135W upgrade kit (13071-00090600)
ASUS PIKE 2008 RAID card (90-S00CS0130T)
ASUS PIKE 2108 H/W RAID card (90-S00CS0150T)
ASUS PIKE 2208 H/W RAID card (90SKC000-M00AN0)
ASUS PIKE 2308 RAID card (90SKC000-M08AN0)
