ASUS RS520 E8 RS8-level3

350,000.00

ASUS RS520 E8 RS8 is a 2U rack server that delivers extreme computing power, high memory and storage capacity, as well as highly-flexible expandability. Engineered with premium components throughout, ASUS RS520 E8 RS8 provides high dependability and exceptional efficiency levels, making it ideal for datacenter deployment, and both small and medium business applications

Categories: ,

Description

ProcessorDual Processor E5-2678 v3
256GB
HDD Bays8 3.5 INCH HDD BAY
Form Factor2U

KEY SPECIFICATIONS

Processor / System Bus
QPI 6.4 / 8.0 / 9.6 GT/s
*Refer to support page for more information
Intel® Xeon® processor E5-2600 v4 product family (145W) *
Intel® Xeon® processor E5-2600 v3 product family(145W)*
2 x Socket R3 (LGA 2011-3)
Core LogicIntel® C612 PCH
MemoryMemory Type :
2400 /2133 /1866/1600 DDR4 RDIMM
DDR4 1600/2133 /2400 /1866 LRDIMM
Total Slots : 16 (4-channel per CPU, 8 DIMM per CPU)
Memory Size :
32GB, 64GB LRDIMM
32GB, 4GB, 8GB, 16GB RDIMM
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Capacity : Maximum up to 1024GB LRDIMM
StorageSAS Controller :
ASUS PIKE II 3008 8-port SAS HBA card(Optional)
SATA Controller :
1 x M.2 connector
Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 0, 1, 10, 5 )
Intel® C612
9 x SATA3 6Gb/s ports
Expansion Slots3 + 1

Low-profile
1 x PCI-E Gen3 x16 (x8 link)
2 x PCI-E Gen3 x8 (x8 link)
1 x OCP Mezzanine (Gen3 x8 link)*

* Support for MCB-10G-2S (Dual Port 10 Gigabit/s Ethernet card) (optional)

Networking2 x Intel® I210AT + 1 x Mgmt LAN
GraphicAspeed AST2400 with 32MB VRAM
On Board I/O
  • Front I/O Ports
    2 x USB 2.0 ports
    1 x VGA port
  • Rear I/O Ports
    2 x RJ-45 ports
    1 x RJ-45 Mgmt LAN port
    2 x USB 3.0 ports
    1 x VGA port
    1 x PS/2 KB/MS port
    1 x External Serial Port(Optional)
    1 x Q-Code/Port 80 LED
OS SupportWindows® Server 2012 R2

*Subject to change without any notice
Ubuntu
SuSE® Linux Enterprise Server
Windows® Server 2008 R2
Windows® Server 2012
Windows® Server 2016
Citrix XenServer
RedHat® Enterprise Linux
VMware
CentOS

Management SolutionASWM Enterprise
On-Board ASMB8-iKVM for KVM-over-IP
Regulatory ComplianceBSMI, C-Tick, CE, FCC(Class A)
Dimensions615mm x 444mm x 88mm
24.21″ x 17.48″ x 3.46″
WeightNet Weight: 14.61 Kg
Gross Weight: 21.28 Kg
Power Supply1+1 Redundant 770W 80PLUS Gold Power Supply

Rating: 100-127Vac/200-240Vac,10A/5A ,50-60Hz, Class I

EnvironmentOperation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
Accessory Box1 x Bag of Screws
1 x AC Power Cable
Optional ItemsASUS PIKE 2008 RAID card (90-S00CS0130T)
ASUS PIKE 2008/IMR RAID card (90-S00CS0140T)
ASUS PIKE 2108-32PD H/W RAID card (90-S00CS0150T)
ASUS PIKE 2208 H/W RAID card (90SKC000-M00AN0)
ASUS PIKE 2308 RAID card (90SKC000-M08AN0)

Part List

ChassisASUS R20D 2U Rackmount Chassis
MBASUS Z9PE-D16-10G/Dual Server board
HDD Backplane“1 x RS720-E7-RS24-EG SAS/SATA Backplane (BP24LX-R21C)
(60SC02W0-SC0A02)
Front Panel Board1 x Front I/O Board (FPB-R20A) (60SC00V0-SC0A02)
CPU Heatsink/ Cooler2 x CPU Heatsink (13071-00090800)
Power Supply Unit“1 x 770W Redundant Power Supply (04G184004921)
(2 x Power Supply Module default for North America)”
HDD Tray24 x Hot-swap 2.5″ HDD trays (13GS120AM021-1)
Fan4 x System Fans (80mm x 38mm) (13G074154010)
Fan Holder4 x Fan Holder (13GS1600P040-1 + 13GS1600P010-1)
Mounting Rails1 x Friction rail kit (13GS190AM042-1)
