Processor / System Bus
|
2 x Socket P (LGA 3647)
1st and 2nd Gen Xeon® Scalable Processor Family (205W)
*Refer to support page for more information
*Please refer to overview for details
UPI (10.4 GT/s) |
| Generation |
E9 |
| Core Logic |
Intel® Lewisburg PCH C621 |
| Memory |
Total Slots : 16 (6-channel per CPU, 8 DIMM per CPU)
Capacity : Maximum up to 4096GB LR-DIMM 3DS
Memory Type :
DDR4 2933/2666 RDIMM
DDR4 2933/2666 LRDIMM
DDR4 2666 LR-DIMM 3DS
Memory Size :
64GB, 32GB, 16GB RDIMM
128GB, 64GB, 32GB LRDIMM
128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information |
| Expansion Slots |
1 x PCIe 3.0 x16 Slot(Gen3 x16 link); FH,HL (CPU1)
1 x PCIe 3.0 x8 Slot(Gen3 x8 link); FH,HL (CPU2)
1 x OCP 2.0 Mezzanine Conn.(Gen3 x16 link)(CPU1) |
| Storage |
SATA Controller :
Intel® C621
SATA Controller :
Intel® C621
2 x M.2 connector
Optional kits Controller :
ASUS PIKE II 3008 8-port SAS HBA card
ASUS PIKE II 3108 8-port SAS HW RAID card |
| Drive Bays |
4 x 3.5″ Hot-swap Storage Bays (Backplane Supports 4 x 3.5″ or 2.5″ SATA/SAS Devices) |
| Auxiliary Storage FDD/CD/DVD |
Optinal Slim-type DVD Drive |
| Networking |
2 x Intel X722 + Marvel PHY 88E1514 (PHY) + 1 x Mgmt LAN |
| Graphic |
Aspeed AST2500 with 64MB VRAM |
| Front I/O Ports |
2 x USB 3.0 ports
1 x VGA port |
| Rear I/O Ports |
2 x USB 3.0 ports
1 x VGA port
2 x RJ-45 1GbE LAN ports
1 x RJ-45 Management port |
| Switch/LED |
Rear:
– 1 x Power Switch/LED
– 1 x Q-Code/Port 80 LED
– 1 x Locatation LED
– 1 x Message LED
Front:
– 1 x Power Switch/LED
– 1 x Location Switch/LED
– 1 x Reset Switch
– 1 x Message LED
– 4 x LAN LED (LED1~2 for on-board LAN, 3~4 for OCP LAN) |
| OS Support |
Please find the latest OS support from https://www.asus.com/event/Server/OS_support_list/OS.html |
| Management Solution |
ASUS Control Center
ASMB9-iKVM for KVM-over-IP |
| Regulatory Compliance |
BSMI, CE, FCC(Class A) |
| Dimensions |
616mm x 444mm x 44mm
24.21″ x 17.48″ x 1.73″ |
| Form Factor |
1 U |
| Weight |
Net Weight: 11 Kg
Gross Weight: 17 Kg |
| Power Supply |
1+1 Redundant 770W 80 PLUS Platinum Power Supply
Rating: 100-127/200-240 Vac, 10A/5A, 50-60Hz, Class I
Up to 205W CPU1+1 Redundant 450W 80 PLUS Gold Power Supply
Rating: 100-127/200-240 Vac, 5.5A/3A, 50-60Hz, Class I
Up to 85W CPU |
| Note |
For the full function of the system, please install both CPUs on CPU sockets. |
