Asus Rack Server RS720 E7 RS12 level 1


Based on the Intel® Socket R E5-2600  processor platform, the Asus RS720 E7 RS12

server offers customers assured quality of service with high memory capacity, outstanding power efficiency, quad LAN, and mass storage. It also enables comprehensive server management and flexible RAID, offering functional integration that makes it an excellent all-round choice for any IT application.

Out of stock



ProcessorSingle Processor E5-2620 v2
HDD Bays12 3.5 inch HDD BAY
Form Factor2U


Processor / System Bus
QPI 6.4 / 7.2 / 8.0 GT/s
Intel® Xeon® processor E5-2600 product family (150W) *1
Intel® Xeon® processor E5-2600 v2 product family (150W) *1
2 x Socket 2011
Core LogicIntel® C602-A PCH
MemoryTotal Slots : 16 (4-channel per CPU, 8 DIMM per CPU)
Capacity : Maximum up to 512GB LRDIMM/Maximum up to 512GB RDIMM/Maximum up to 128GB UDIMM
Memory Type :
DDR3 with ECC RDIMM 1066/1600/1333/800/1866*
DDR3 UDIMM 1333/1866/1600/1066*
LRDIMM 1066/1333/1866 DDR3*
Memory Size :
2GB, 4GB, 1GB, 32GB, 8GB, 16GB RDIMM
StorageSATA Controller :
4 x SATA2 3Gb/s ports
Intel® C602-A
2 x SATA3 6Gb/s ports
Intel® Rapid Storage Technology(RST) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
SAS Controller :
ASUS PIKE 2108-32PD 8-port SAS2 6G RAID card (Optional)
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card(Optional)
ASUS PIKE 2008 8-port SAS2 6G RAID card (Optional)
ASUS PIKE 2208 8-port SAS 6G HW RAID card (Optional)
ASUS PIKE 2308 8-port SAS 6G RAID card (Optional)
Expansion SlotsLow-profile
4* PCI-E x16 (Gen3 x16 Link) + 1*PCI-E x16 (Gen3 x8 Link)
3* PCI-E x16 (Gen3 x16 Link) + 3*PCI-E x16 (Gen3 x8 Link)1* PIKE Slot for Stroage Enhancement
Networking1 x Quad Port Intel Ethernet Controller i350-AM4 + 1 x Mgmt LAN
GraphicAspeed AST2300 with 16MB VRAM
On Board I/O1 x VGA port
1 x PS/2 keyboard port
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x Internal A Type USB Port
1 x PS/2 mouse port
5 x RJ-45 ports (One for ASMB6-iKVM)
OS SupportSuSE® Linux Enterprise Server 11.2 32/64-bit
CentOS 5.6 32/64-bit
RedHat® Enterprise Linux AS5.6/6.0 32/64-bit
Windows® Server 2008 Enterprise 32/64-bit
VMWare ESX4.1/ESXi4.1*Subject to change without any notice
Windows® Server 2008 R2
Management SolutionOn-Board ASMB6-iKVM for KVM-over-IP
Regulatory ComplianceCE, BSMI, FCC(Class A), C-Tick
Dimensions615mm * 444mm * 87.0mm
Power Supply770W (80+) (Gold level) 1+1 Redundant Power Supply (following different configuration by region)
EnvironmentOperation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
Accessory Box1 x Bag of Screws
1 x AC Power Cable
Optional ItemsASUS PIKE 2008 RAID card (90-S00CS0130T)
ASUS PIKE 2008/IMR RAID card (90-S00CS0140T)
ASUS PIKE 2108-32PD H/W RAID card (90-S00CS0150T)
ASUS PIKE 2208 H/W RAID card (90SKC000-M00AN0)
ASUS PIKE 2308 RAID card (90SKC000-M08AN0)

Part List

ChassisASUS R20D 2U Rackmount Chassis
MBASUS Z9PE-D16 Server board
HDD Backplane1 x RS720-E7/RS12 SAS/SATA Backplane (BP12LX-R20A) (60SC01X0-SC0A03)
Front Panel Board1 x Front I/O Board (FPB-R20A) (60SC00V0-SC0A02)
CPU Heatsink/ Cooler1 x CPU Heatsink (13071-00090800)
Power Supply Unit1 x 770W Redundant Power Supply (04G184004921)
HDD Tray12 x Hot-swap 3.5″ HDD trays (13GS1I0AM010-1)
Fan4 x System Fans (80mm x 38mm) (13G074154010)
Fan Holder4 x Fan Holder (13GS1600P040-1 + 13GS1600P010-1)
Mounting Rails1 x Rail kit
